这个小板块更偏向信息系统开发技术，主要讲述 Java Web 开发过程中的常见 BUG 以及解决方法

Spring Boot 启动失败

端口占用

application.yml配置文件中一般会指定启动端口（没指定则默认 8080 端口）
如果目标端口被占用，就会出现以下报错信息：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
***************************
APPLICATION FAILED TO START
***************************

Description:

Web server failed to start. Port 8080 was already in use.

Action:

Identify and stop the process that's listening on port 8080 or configure this application to listen on another port.


Process finished with exit code 1

建议更换端口号，必要时关闭占用端口的进程；

依赖注入失败

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
***************************
APPLICATION FAILED TO START
***************************

Description:

A component required a bean of type 'com.rngad33.ark.service.ThumbService' that could not be found.


Action:

Consider defining a bean of type 'com.rngad33.ark.service.ThumbService' in your configuration.


Process finished with exit code 1

检查要注册的类是否打上了 @Component，@Service 等注解；

循环依赖

Spring IOC 容器注册 Bean 对象存在这样一个机制：如果待注册对象存在依赖的对象，则会优先注册被依赖对象，依此类推；
如果出现了这样一种情况：A 依赖 B，B 依赖 C，C 又依赖 A，就会发生相互等待现象，导致框架启动失败，这种现象就是循环依赖；

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
***************************
APPLICATION FAILED TO START
***************************

Description:

The dependencies of some of the beans in the application context form a cycle:

   pictureController
      ↓
   myCacheManager
┌─────┐
|  pictureServiceImpl
↑     ↓
|  jsoupTemplateFromBing
└─────┘


Action:

Relying upon circular references is discouraged and they are prohibited by default. Update your application to remove the dependency cycle between beans. As a last resort, it may be possible to break the cycle automatically by setting spring.main.allow-circular-references to true.


Process finished with exit code 1

这个问题一般是没有处理好不同对象间的依赖关系导致的，开发者应当优先优化依赖关系，以打破依赖循环；
如果实在没有办法打破，可以使用 @Lazy 注解指定 Bean 对象延迟加载，即使用时才注册到 IOC 容器；

数据库问题

在 Spring Boot 项目中使用了 MyBatis 原生框架或者 MyBatis-Flex 增强框架，你可能会遇到这个启动报错：

1
Caused by: java.lang.IllegalArgumentException: Property 'sqlSessionFactory' or 'sqlSessionTemplate' are required at org.springframework.util.Assert.notNull(Assert.java:172) ~[spring-core-6.1.15.jar:6.1.15] at org.mybatis.spring.support.SqlSessionDaoSupport.checkDaoConfig(SqlSessionDaoSupport.java:122) ~[mybatis-spring-3.0.4.jar:3.0.4] at org.mybatis.spring.mapper.MapperFactoryBean.checkDaoConfig(MapperFactoryBean.java:69) ~[mybatis-spring-3.0.4.jar:3.0.4] at org.springframework.dao.support.DaoSupport.afterPropertiesSet(DaoSupport.java:44) ~[spring-tx-6.1.15.jar:6.1.15] at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.invokeInitMethods(AbstractAutowireCapableBeanFactory.java:1853) ~[spring-beans-6.1.15.jar:6.1.15] at org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory.initializeBean(AbstractAutowireCapableBeanFactory.java:1802) ~[spring-beans-6.1.15.jar:6.1.15] ... 79 common frames omitted

极有可能是缺少 JDBC 相关依赖，需要手动引入（MyBatis-Plus 实测不存在这个问题）；

运行时异常

<- To be continued _(:3 ∠)__
